Description
Technical data
- Flow rate: max. 340 m3/h
- Head: max. 92 m
- Liquid temperature: -25 to +140 °C
- Operating pressure: max. 16 bar
Applications
- Heating systems
- Domestic hot-water systems
- Cooling and air-conditioning systems.
Features and benefits
- Low energy consumption
- Adaptation to existing operating conditions
- Simple installation
- Factory-fitted differential-pressure sensor
- Fitted with motors equivalent to IE3 (IE4 up to 11 kW).
Options
- Wireless remote control by means of bGrundfos GO Remote
- Communication via GENIbus, LONWorks, PROFIBUS DP, Modbus RTU, 3G/4G cellular, GRM GiC 3G/4G, BACnet MS/TP, PROFINET, Modbus TCP, BACnet IP,EtherNet/IP, GRM IP
- Twin-head versions with built-in alternation and standby function.
